HAIBIKE LYKE 10 2024
HAIBIKE LYKE 10 2024
Couldn't load pickup availability
HAIBIKE LYKE 10
Adventure is just a step away: right outside your door. Get on your Haibike, take off and experience your surroundings. Everyone benefits from the feeling of being “empowered”, pushing the pedals and feeling the power of turbo mode – regardless of age, fitness or riding ability. Our new eBike generation makes it possible to ride further than ever before, making the world around us even more exciting than we dreamed possible.
Specification
MOTOR: Fazua Ride60
BATTERY: Fazua Energy InTube 430Wh Battery
FORK: Rockshox Lyrik Select
SHOCK: Rockshox Air Deluxe Select Plus
WHEELS: WTB Hollow rim ST i30 TCS
TYRES: Schwalbe Wicked Will Evo Super Ground
DERALLIEUR: Sram NX
SHIFTER: Sram SX
CHAIN: Sram Eagle
CASSETTE: Sram 10-52
BRAKES: Shimano M6120 Brakes
CRANKSET: Rotor E-Kapic
SADDLE: Selle Italia Model X
BARS: XLC FlowBy Dia. 31.8 mm
STEM:
PEDDLES: Freeridepedal
GRIPS: Haibike
SEAT POST:
PERMISSIBLE TOTAL VEHICLE WEIGHT: 120kg
GEOMETRIES
|
Bike Size |
Small |
Medium |
Large |
X-Large |
|
Rider hight |
5'2" - 5'6" |
5'6" - 5’10" |
5'10" - 6'1" |
6'1" - 6'4" |
| SIZE | S | M | L | XL |
| A - Top Tube Length | 562mm | 592mm | 622mm | 652mm |
| B - Seat Tube Length | 410mm | 440mm | 470mm | 500mm |
| C - Seat Tube Angle | 74° | 74° | 74° | 74° |
| D - Head Tube Length | 110mm | 120mm | 130mm | 140mm |
| E - Steering Angle | 65° | 65° | 65° | 65° |
| F - Chain Stay Length | 450mm | 450mm | 450mm | 450mm |
| G - Wheel Base | 1195mm | 1227mm | 1259mm | 1290mm |
| I - BB-Drop | -25mm | -25mm | -25mm | -25mm |
| K - Stack | 611mm | 620mm | 629mm | 638mm |
| L - Reach | 424mm | 452mm | 479mm | 506mm |
